DECONSTRUCTING DOTTY

A next generation Scala compiler

Felix Mulder

ABOUT ME

• github.com/felixmulder
• Graduated last winter from LTH
• Built the new 2.12.x Scaladoc
• Research fellow EPFL, working on Dottydoc at LAMP
• Compiler Engineer working on Dotty with Martin Odersky at LAMP

Scala

Camp I

“Scala is a better Java, type inference!”

Camp F

“Liek OMG, a monad’s just a monoid in the category of endofunctors”

“There is not agreement on what is ”best“, so all we can really do is try to find a local optimum. But finding that optimum is what drives me”

WHAT IS DOTTY?

• A compiler to try out new language and compiler concepts
• Developed at LAMP EPFL
• Nearing beta readiness

DOTTY’S FOCUS

• A proven sound foundation - DOT
• Focus on simplification
• Compilation speed
• Library defined optimizations
• Developer usability

KEY DIFFERENCES

• No more procedure syntax
• Union Types
• Intersection Types
• Trait Parameters
• TASTY

TASTY

• Pickling format
• Typed Trees
• Efficiently stored in bytecode
• Interop between binary incompatible compilers

Procedure Syntax

def foo {}
// error!

def foo = {}
// res: Unit

Intersection and Union Types

• A & B is the greatest lower bound: a supertype of all subtypes of both A and B
• A | B is the least upper bound: a subtype of all supertypes of both A and B

Union Types for Enums

case object Monday
case object Tuesday
case object Wednesday
case object Thursday
case object Friday
case object Saturday
case object Sunday

type Weekend = Saturday.type | Sunday.type
type Weekday = Monday.type | Tuesday.type...
type AnyDay  = Weekday | Weekend

Patternmatch exhaustivity checks

(Saturday: Weekend) match {
case Sunday => // incomplete!
}

Intersection Types are the new `with`

trait A {
def foo: Int
}
trait B {
def bar: Int
}

def baz(ab: A & B) = ab.foo + ab.bar

Trait Parameters instead of Early Initializers

trait Super {
def x: String
println(x)
}
class Foo extends Super {
val x = "hello"
}

new Foo
// prints: null

trait Super(x: String) {
println(x)
}
class Foo extends Super("hello")

new Foo
// prints: "hello"

So now the fun stuff - Compiler internals

javac pipeline

1. Parse
2. Enter
3. Annotate
4. Attribue
5. Flow
6. Desugar
7. Generate

dotty pipeline

Regular Phases

Fused Phases

Let’s create a MiniPhase!

• A simplistic static linter
• This linter really cares about division by zero

Coding time!

So why aren’t we putting things like this in Dotty?

• Principle of least power
• Domain specific optimizations
• …maybe we have something more fitting?

Dotty-Linker to the rescue!

• Whole program optimization
• Call graph
• User defined rewrite rules

Reimplementing our linter

@rewrites object rules {
def customFancyWarning(x: Int | Double | ... | Numeric[_]) =
Warn(pattern = x / 0,
msg = "division by zero, you fool!")
}

Why do we need an optimizer?

Scala provides:

• higher-order types
• generic methods
• generic classes
• multiple inheritance
• pattern matching
• lazy evaluation
• garbage collection

Example

public double average(int[] data) {
int sum = 0;
for(int i = 0; i < data.length; i++) {
sum += data[i];
}
return sum * 1.0d / data.length;
}

def average(xs: Array[Int]) =
xs.reduce(_ + _) * 1.0 / xs.size

Java

public double average(int[] data) {
int sum = 0;
for(int i = 0; i < data.length; i++) {
sum += data[i];
}
return sum * 1.0d / data.length;
}

• Range check
• Addition
• Index increment

Scala

def average(xs: Array[Int]) =
xs.reduce(_ + _) * 1.0 / x.size

def reduce(op: Function2[Obj, Obj, Obj]): Obj = {
var first = true
var acc: Obj = null
this.foreach { e =>
if (first) {
acc = e
first = false
} else acc = op.apply(acc, e)
}
acc
}

def foreach(f: Funtion1[Obj, Obj]) {
var i = 0
val len = length
while (i < len) {
f.apply(this(i))
i += 1
}
}

Compiler needs to lower generics

def plus[T](a: T, b: T)(implicit num: Numeric[T]): T =
num.plus(a, b)

def plus(a: Object, b: Object, num: Numeric): Object =
num.plus(a, b)

plus(1, 1)

unbox(plus(box(1), box(1), intNum))

Specialize all the things!

trait T[A1, A2, ..., An]

trait T[A1, A2, ..., An] {
def foo[B1, B2, ..., Bm] = ???
}

Existing solutions for Scala 2

• @specialized
• Miniboxing

Specialization

def foo[@specialized A](a: A) = ???

Specialization

• Mark types using @specialized
• Can specify for which types e.g:
  @specialized(Int)
• 10^n
• No inheritance

Miniboxing

• Reduces the factor to: 3^n
• Handles inheritance

trait Function3[-T1, -T2, -T3, +R]

Both: how many specializations are needed?

• Specialization: 10000 classes
• Miniboxing: 81 classes

Are they asking the right question though?

Dotty Linker’s approach

Auto-Specialization in Dotty Linker

• Takes your program & libraries, analyzes how you use them
• Sees what instantiations are needed
• Specializes them
• No need to annotate types

def foo[T](x: Seq[T], id: Int) = x(id)

• Type specialization removes boxing
• Term specialization removes virtual dispatch

Status

• Dotty
  • http://github.com/lampepfl/dotty
  • Example projects working, libraries are being ported
  • User experience: nearing beta
• Dotty Linker
  • http://github.com/dotty-linker/dotty
  • Rewrite rules are being tested using property based testing
  • Features being ported to Dotty
  • User experience: alpha

Developer Usability

Thank you!
